MagicLine Laser Visible Outdoors Class 2M

SKU: 750129001
£2,639.00
Checkout Secure
Need more info? Call us +61 8 9335 1718

The New MagicLine Laser - Visible outdoors and Eye Safe. a world-first laser that is visitbompact high-performance module

The MagicLine laser is a new generation of high-powered laser, visible outdoors and only Laser Class 2M.

With an optical output power of 600 mW in compliance with laser class 2M safety standards, the ZQ1-MagicLine combines unrivalled performance with reliable safety.

This combination makes it the world's brightest eye-safe laser in its class and sets new standards in laser technology.

Wherever high output power, excellent beam characteristics and industrial-grade design are required, the MagicLine is the right choice.

The user can manually focus the beam the optimum line witdth and visibility can be achieved. Combined with its intelligent monitoring functions, the laser allows for high power stability even in harsh environments. The integrated active peltier cooling supports this function by keeping the laser diode constantly in the optimal temperature range.

  • Manually focusable
  • Active cooling integrated
  • TTL modulation up to 200 kHz
  • Analog intensity control
  • IP 67
  • Certified according to the railway standard: DIN EN 61373:2011-04
  • PC control via Graphical User Interface (GUI)


Weight 740 g
Dimensions 158.5 × 65.2 × 51.5 mm
Wavelength

520nm

Output power

600 mW

Fan Angle

70 degrees

Projection

line

Focus

manual focus

Modulation

analog, digital

Supply voltage

12 VDC – 24 VDC

IP protection class

IP 67

Applications

Transport & Logistics, Materials Processing (Timber, Glass, Stone), Machine Vision
