Fluke Amprobe AM-270 Industrial Multimeter With Bar Grapgh Display (item no. 3524999)

Amprobe AM-270 Industrial Multimeter w/ Bar Graph Display

SKU: 3524999

Not Available

Need more info? Call us +61 8 9335 1718

Price Match International Orders Tax Removed

(item no. 3524999)

Amprobe’s AM-270 is a commercial, true-rms multimeter for electrical and HVAC applications and is dedicated to electrical and HVAC professionals. Safety rated to CAT IV 600 V and CAT III 1000 V for outdoor and indoor applications requiring direct connection to main panel of the building or measurement of the outdoor wiring connecting building the utility transformer. This true-rms multimeter measures complete range of electrical parameters including voltage, current, resistance and frequency. It also covers HVAC application with temperature, capacitance and micro amps functions. True-rms sensing for superior accuracy.

Features

Digital multimeter measures alternating current (AC) and direct current (DC) to 10 amp, AC voltage and DC voltage to 1,000 volts (V), resistance to 50 megaohms, capacitance to 10,000 microfarads, frequency to 125 kilohertz (kHz), and microcurrent to 5,000 microamp
True RMS (root mean square) sensing meter provides accurate readings when measuring linear or non-linear loads, where the current or voltage has a sinusoidal or nonsinusoidal waveform
K-type thermocouple probe measures temperature
Can be connected to a computer for data transfer and analysis
Meets International Electrotechnical Commission (IEC) safety standard 61010 and is certified for category III installations up to 1,000V and category IV installations up to 600V
Has 18 different features
Measures AC/DC voltage up to 1000V, current, resistance, frequency, capacitance and temperature
Auto and manual ranging
Large, easy to read LCD display
Automatic power off when tester is not in use

Specifications

FEATURE	AM-250	AM-270
AC Voltage	400.0 mV, 4.000 V, 40.00 V, 400.0 V, 1000 V	50.00 mV, 500.0 mV, 5.000 V, 50.00 V, 500.0 V, 1000 V
DC Voltage	400.0 mV, 4.000 V, 40.00 V, 400.0 V, 1000 V	50.00 mV, 500.0 mV 5.000 V, 50.00 V, 500.0 V, 1000V
Resistance	400.0 Ω, 4.000 kΩ, 40.00 kΩ, 400.0 kΩ 4.000 MΩ, 40.00 MΩ	50.00 Ω, 500.0 Ω, 5.000 kΩ, 50.00 kΩ, 500.0 kΩ, 5.000 MΩ, 50.00 MΩ
AC/DC Current	40.00 µA, 400.0 µA, 400.0 mA, 4000 mA, 4.000 A, 10.00 A	50.00 µA, 500.0 µA, 500.0 mA, 5000 mA, 5.000 A, 10.00 A
Frequency	5.000 Hz, 50.00 Hz, 500.0 Hz, 5.000 kHz, 50.00 kHz, 500.0 kHz, 1.000 MHz	5Hz → 125 kHz for all setups except: 5Hz → 1kHz for 500V and 1000V ranges 5 Hz → 20 kHz for 50 V range
Capacitance	500.0 nF, 5.000 µF, 50.00 µF, 500.0 µF , 3000 µF	50.00 nF, 500.0 nF 5.000 µF, 50.00 µF, 500.0 µF, 9999 µF
Temperature	-4 °F → 572 °F (-20 °C → 300 °C)	-58 °F → 1832 °F (-50 °C → 1000 °C)
Data recording	–	Records peak, max, min, max-min
Relative zero mode	–	•

Specifications
Display	-4/5 digits 5000 counts LCD display
Update rate	Digital Data 5 per second nominal;52 Segments Bar-graph 60 per second nominal
Power supply	Single standard 9 V battery NEDA1604, JIS006P or IEC6F22
Special features	Data-Hold; Range-Hold; Backlighted Display; Optional PC-interface capabilities
Special features	50ms Record MAX-MIN readings at fast 20/second measurement mode; 5ms Crest (Instantaneous Peak-Hold) MAX-MIN readings; Relative-Zero offset mode; Zoom 5x analog pointer at 60/s
Accessories	Test leads (pair); Battery (installed); User’s manual; banana plug K type thermocouple
Optional PC-interface capabilities	50 ms Record MAX-MIN readings at fast 20/second measurement mode; 5ms Crest (Instantaneous Peak-Hold) MAX-MIN readings; Relative-Zero offset mode; Zoom 5x analog pointer at 60/s

Shipping

This Item Ships from Fremantle, Perth, Western Australia

Please allow 2 - 10 days for your order to arrive.

Although Most Stocked Products will generally Ship Overnight. We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!

Returns are easy.

simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!

Description

(item no. 3524999)

Features

Digital multimeter measures alternating current (AC) and direct current (DC) to 10 amp, AC voltage and DC voltage to 1,000 volts (V), resistance to 50 megaohms, capacitance to 10,000 microfarads, frequency to 125 kilohertz (kHz), and microcurrent to 5,000 microamp
True RMS (root mean square) sensing meter provides accurate readings when measuring linear or non-linear loads, where the current or voltage has a sinusoidal or nonsinusoidal waveform
K-type thermocouple probe measures temperature
Can be connected to a computer for data transfer and analysis
Meets International Electrotechnical Commission (IEC) safety standard 61010 and is certified for category III installations up to 1,000V and category IV installations up to 600V
Has 18 different features
Measures AC/DC voltage up to 1000V, current, resistance, frequency, capacitance and temperature
Auto and manual ranging
Large, easy to read LCD display
Automatic power off when tester is not in use

Specifications

FEATURE	AM-250	AM-270
AC Voltage	400.0 mV, 4.000 V, 40.00 V, 400.0 V, 1000 V	50.00 mV, 500.0 mV, 5.000 V, 50.00 V, 500.0 V, 1000 V
DC Voltage	400.0 mV, 4.000 V, 40.00 V, 400.0 V, 1000 V	50.00 mV, 500.0 mV 5.000 V, 50.00 V, 500.0 V, 1000V
Resistance	400.0 Ω, 4.000 kΩ, 40.00 kΩ, 400.0 kΩ 4.000 MΩ, 40.00 MΩ	50.00 Ω, 500.0 Ω, 5.000 kΩ, 50.00 kΩ, 500.0 kΩ, 5.000 MΩ, 50.00 MΩ
AC/DC Current	40.00 µA, 400.0 µA, 400.0 mA, 4000 mA, 4.000 A, 10.00 A	50.00 µA, 500.0 µA, 500.0 mA, 5000 mA, 5.000 A, 10.00 A
Frequency	5.000 Hz, 50.00 Hz, 500.0 Hz, 5.000 kHz, 50.00 kHz, 500.0 kHz, 1.000 MHz	5Hz → 125 kHz for all setups except: 5Hz → 1kHz for 500V and 1000V ranges 5 Hz → 20 kHz for 50 V range
Capacitance	500.0 nF, 5.000 µF, 50.00 µF, 500.0 µF , 3000 µF	50.00 nF, 500.0 nF 5.000 µF, 50.00 µF, 500.0 µF, 9999 µF
Temperature	-4 °F → 572 °F (-20 °C → 300 °C)	-58 °F → 1832 °F (-50 °C → 1000 °C)
Data recording	–	Records peak, max, min, max-min
Relative zero mode	–	•

Specifications
Display	-4/5 digits 5000 counts LCD display
Update rate	Digital Data 5 per second nominal;52 Segments Bar-graph 60 per second nominal
Power supply	Single standard 9 V battery NEDA1604, JIS006P or IEC6F22
Special features	Data-Hold; Range-Hold; Backlighted Display; Optional PC-interface capabilities
Special features	50ms Record MAX-MIN readings at fast 20/second measurement mode; 5ms Crest (Instantaneous Peak-Hold) MAX-MIN readings; Relative-Zero offset mode; Zoom 5x analog pointer at 60/s
Accessories	Test leads (pair); Battery (installed); User’s manual; banana plug K type thermocouple
Optional PC-interface capabilities	50 ms Record MAX-MIN readings at fast 20/second measurement mode; 5ms Crest (Instantaneous Peak-Hold) MAX-MIN readings; Relative-Zero offset mode; Zoom 5x analog pointer at 60/s
