Fluke PTi120 9HZ 400C,120X90 Pocket Thermal Imager BY2; 9HZ; 400C

SKU: 5302512
£740.00
Checkout Secure
Need more info? Call us +61 8 9335 1718

The new Fluke Pocket Thermal Imager puts the power to minimize downtime in everyone’s hands with the right tool at the right time.

The bigger the problem, the faster you need to solve it.  As the first line of defense for easy troubleshooting, the PTI120 empowers you to stop fighting fires on the job, and start preventing them.

Includes:

  • USB cable
  • Soft transport bag
  • Adjustable lanyard
  • Free download: Fluke Connect software and user manual

Features:

  • Continuous touchscreen IR-Fusion™, slide your finger across the screen to adjust the setting
  • Automatically organize and file thermal images with Fluke Connect Asset Tagging
  • Fully radiometric thermal imager with 120 x 90 infrared resolution
  • 3.5" LCD touchscreen display for easy troubleshooting
  • Can withstand drop up to 1 meter
  • Water and dust resistant—IP54 enclosure rating

Specifications:

  • Infrared resolution: 120 x 90 (10,800 pixels)
  • IFOV (spatial resolution): 7.6 mRad, D:S 130:1
  • Field of View: 50°H x 38°V
  • Minimum focus distance: 50cm
  • Focus system: Fixed focus
  • Display: 3.5" touchscreen
  • Display resolution: 320 x 240 LCD
  • Thermal sensitivity(NETD): 60mK
  • Frame rate: 9 Hz
  • Data transfer: Mini USB
  • Wireless connectivity: Yes
  • Memory: >2GB internal flash memory
  • Battery: Internal rechargeable lithium ion battery
  • Battery charging time: 1.5 hours approx.
  • Temperature measurement: -20° to 400°
  • Safety: IEC 61010-1: Pollution degree 2
  • Electromagnetic capability: EN 61326-1, CISPR 11: Group 1, Class A
  • Dimensions (L x W x H): 25mm x 127mm x 89mm
  • Weight: 0.233kg
Shipping This Item Ships from Fremantle, Perth, Western Australia
Please allow 2 - 10 days for your order to arrive.

Although Most Stocked Products will generally Ship Overnight. We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!

Returns are easy.

simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!

Description

The new Fluke Pocket Thermal Imager puts the power to minimize downtime in everyone’s hands with the right tool at the right time.

The bigger the problem, the faster you need to solve it.  As the first line of defense for easy troubleshooting, the PTI120 empowers you to stop fighting fires on the job, and start preventing them.

Includes:

  • USB cable
  • Soft transport bag
  • Adjustable lanyard
  • Free download: Fluke Connect software and user manual

Features:

  • Continuous touchscreen IR-Fusion™, slide your finger across the screen to adjust the setting
  • Automatically organize and file thermal images with Fluke Connect Asset Tagging
  • Fully radiometric thermal imager with 120 x 90 infrared resolution
  • 3.5" LCD touchscreen display for easy troubleshooting
  • Can withstand drop up to 1 meter
  • Water and dust resistant—IP54 enclosure rating

Specifications:

  • Infrared resolution: 120 x 90 (10,800 pixels)
  • IFOV (spatial resolution): 7.6 mRad, D:S 130:1
  • Field of View: 50°H x 38°V
  • Minimum focus distance: 50cm
  • Focus system: Fixed focus
  • Display: 3.5" touchscreen
  • Display resolution: 320 x 240 LCD
  • Thermal sensitivity(NETD): 60mK
  • Frame rate: 9 Hz
  • Data transfer: Mini USB
  • Wireless connectivity: Yes
  • Memory: >2GB internal flash memory
  • Battery: Internal rechargeable lithium ion battery
  • Battery charging time: 1.5 hours approx.
  • Temperature measurement: -20° to 400°
  • Safety: IEC 61010-1: Pollution degree 2
  • Electromagnetic capability: EN 61326-1, CISPR 11: Group 1, Class A
  • Dimensions (L x W x H): 25mm x 127mm x 89mm
  • Weight: 0.233kg
