geo-FENNEL FL 510HV-G Tracking (LC 2) Dual Grade Rotating Laser with FR 80 MM Tracking Receiver

SKU: 231700
£2,045.00
Checkout Secure
Need more info? Call us +61 8 9335 1718

geo-FENNEL FL 510HV-G Tracking (LC 2) Dual Grade Rotating Laser with FR 88 MM Tracking Receiver

The ideal outdoor laser

Optimized laser for outdoor applications with automatic axis alignment in horizontal and vertical.

geo-Fennel FL 510HV-G Video


  • Including receiver FR 80-MM Tracking with mm-indication
  • Tracking functions:



      • The laser plane is automatically centred to the receiver “on-grade”


        • Vertical: in both X and Y axis
        • Horizontal: one axis X or Y, other axis horizontal self-levelled
        • Indication of grade value in % after completion of tracking process shown on the instrument and remote control display. Zonal control with electronic beam screen avoids spurious measurements caused by crossing laser planes and reflections – increases site safety



  • Fully automatic self-levelling in horizontal, vertical and grade
  • Slope functions:


      • Horizontal:
        • Digital grade setting of X and Y axis up to ±10 %
        • Manual slope setting of X and Y axis
      • Vertical:
        • Direction of X axis can be set up to ±10 % with Y axis self-levelled
        • Direction of X and Z axis can be set manually
  • Automatic TILT function
  • VWS function (Vibration-Wind-Security)
    Rotation will not be stopped due to light ground and wind vibrations
    (combined with TILT function)
  • Zonal control with electronic beam screen (masking)
  • Fully functional 8-channel 2-way RF remote control
  • Li-Ion battery technology

Features

  • Dual Axis Laser
  • Horizontal and vertical
  • Digital grade adjustment
  • Monitored grade (also in tracking mode)
  • TILT function
  • VWS function
  • Tracking function horizontal and vertical
  • Zonal control
  • 90° beam to zenith
  • Illuminated display
  • 2-way RF remote control
  • Manual function
  • Operation with rechargeable Li-Ion or alkaline batteries
  • Dust / water protection IP 66

Includes

  • Receiver FR 80-MM Tracking with clamps for levelling staff and scaffold
  • 2-way RF remote control
  • Li-Ion batteries and charger
  • Vertical mount
  • Telescopic viewfinder
  • 360° horizontal fine adjustment bracket
  • Container

Specifications

Self-levelling range ± 8°
Accuracy horizontal ± 0.5 mm / 10 m
Accuracy vertical ± 1 mm / 10 m
Working range with receiver
  FR 80-MM Tracking Ø
Contact Us
Laser diode / Laser class 2
Horizontal slope setting
X-axis ± 10.000 %
Y-axis ± 10.000 %
X and Y axis Σ ± 14 %
Vertical slope setting
X axis ± 10.000 %
Y(Z) axis horizontal self-levelled
Working range tracking function 90 m*
Rotating speed 300 / 600 / 1100 rpm
Operating time 40 h
Power supply intelligent / Li-Ion
Alkaline batteries (optional)
Remote control range 100 m
Remote control channels 8
Temperature range -10 °C – +50 °C
Dust / water protection IP 66
Weight (instrument only) 3.85 kg
