Leica Disto X3 P2P Kit with DST360 and TRI120 Tripod in Hard Case

SKU: LG887687K
Need more info? Call us +61 8 9335 1718

X3 P2P Kit with DST360 and TRI120 Tripod in Hard Case

  • For LeicaDisto X3 and X4 laser distance meters
  • Provides precise P2P measurements
  • Allows horizontal and vertical angle measurements
  • Made entirely of metal
  • Smart area measurements
  • With measure plan and measure facade

POINT TO POINT MEASURING

The DST 360 transforms your handheld DISTO™ X3 and X4 into a real measurement station, allowing you to accurately measure distances between any two points from one position.

3D POINT MEASUREMENT

Your DISTO™ X3 or X4 in combination with the DST 360 and the DISTO™ Plan app allow you to measure 3 dimensional points. X, Y and Z coordinates are recorded and can be exported into your CAD solution.

METAL DESIGN

The Leica DST 360 is made entirely out of metal. This ensures robustness and precise measurement results.

INTELLIGENT ADAPTER

Technologies used in the adapter extend the measurement possibilities of your DISTO™ X3 and X4. Powered by your DISTO™, the DST 360 exchanges measurement data with your X3 and X4. This allows for horizontal and vertical angle measurements.

PRECISE TARGETING

Fine adjustment on the Leica DST 360 allow you to accurately aim at distant measurement points in seconds.

INCLUDES:

  • DST 360 Adapter for Leica Disto X-Series
  • DST 360 Adapter
  • TRI 120 Tripod
  • Rugged Case
  • Quickstart Guide
  • Calibration Certificate
  • 3-Year Warranty

Error 156: The transverse tilt is greater than +/- 10°
To resolve: Hold the instrument without any transverse tilt


Error 162: Calibration mistake
To resolve: Make sure the device is placed on an absolutely horizontal and flat surface. Repeat the calibration procedure. If the message still occurs, contact the dealer


Error 204: Calculation error
To resolve: Repeat measurements, make sure to follow the sequence according to the manual


Error 205: S910 memory full
To resolve: Delete memory


Error 220 & 224: Hardware error
To resolve: If the message continuously appears, contact the dealer for service


Error 240 & 245: Data transfer error
To resolve: Re-connect device with computer and repeat procedure


Error 252: Temperature too high
To resolve: Let device cool down


Error 253: Temperature too low
To resolve: Let device warm up


Error 254: Battery voltage too low for measurements
To resolve: Change batteries


Error 255: Received signal too weak, measuring time too long
To resolve: Change target surface (i.e. white paper)


Error 256: Received signal too high
To resolve: Change target surface (i.e. white paper)


Error 257: Too much background light
To resolve: Shadow target area


Error 258: Measuring outside of measuring range
To resolve: Correct range


Error 260: Laser beam interrupt
To resolve: Repeat measurement


Error 284: Laser defect
To resolve: If message continuously appears, contact the dealer for service


Error 288-294: Hardware error
To resolve: If message continuously appears, contact the dealer for service


Error 300: Smart base not folded out
To resolve: Fold out Smart Base


Error 301: Device was moved, levelling not valid anymore
To resolve: Perform levelling again. Levelling with invalid levelling is possible, but it will affect the accuracy


Error 302: S910 "Point data transmission" is selected, but WLAN is off
To resolve: Switch on WLAN


Error 303 - 306: Error with Leica DST 360 Adapter
To resolve: Repeat procedure and if message still occurs, contact your dealer


Error 340: WLAN: Data transfer error
To resolve: Repeat procedure


Error 341: Authentication error
To resolve: Use correct password


Error >1000: Hardware error
To resolve: If message continuously appears, contact the dealer for service


Error 14041: Smart Base defect
To resolve: If message continuously appears, contact the dealer for service
