MIT415/2 Insulation & Continuity Tester 10/25/50/100/250/500V + 600 V CAT IV + PI & DAR Factory Calibration Cert:included
Description
Megger MIT415/2 - Insulation and Continuity Tester
- Designed for Electrical and Industrial testing
- Insulation testing up to 1000 V and 200 GΩ range
- Stabilized insulation test voltage
- Single range, faster continuity testing from 0.01 Ω to 1 MΩ
- 600 V Trms AC and DC voltage measurement
The Megger MIT415/2 insulation and continuity tester has been designed for electrical testing by utilities, industrial, commercial and domestic electricians. The wide range of test voltages makes the MIT415 series ideal for the engineer or technician involved with combined applications of both communications circuits and power circuits such as would be found in elevator service/repair and routine maintenance. The low test voltage insulation ranges also makes the MIT415 ideal for ESD testing.
The MIT415/2 and MIT417/2 insulation and continuity testers are designed not just for Electrical and Industrial, but with an exceptionally wide range of applications from electrical installations, cable testing, motor testing, automotive, ESD, panel building, avionics, maintenance etc.
Continuity testing is now significantly faster, and a single auto- ranging 0.01 Ω to 1.0 MΩ function replaces the "ohms" and "kOhms" ranges. Retained are the 200 mA and 20 mA test options.
Replacing the original MIT400 instruments the new units feature a redesigned case, back-stand, and 6 cell battery compartment with separate fuse access. All instruments are over-moulded for increased protection and achieve an IP54 weatherproof rating.
Model applications
These models include all the features required for electricians, technicians and engineers working in a range of industries. Available features are selected to make testing easy and fast in a range of situations.
- Building/Campus electrical maintenance
- Large and small scale electrical installations
- Periodic electrical systems inspection and testing
- Cable testing
Features and Benefits
- CAT IV 600 V rating - provides greater safety when testing at higher voltage levels
- Adjustable insulation test voltages - provides 250 V to 1000 V or 50 V to 1000 V. The special applications instrument (Model MIT40X) offers test voltages from 10 V to 100 V in 1 V steps.
- Dual digital display readout - allows display of complimentary test information simultaneously (for example: M½ plus test voltage or M½ plus leakage current)
- Digital and analog arc display - includes not only the digital readout but also Megger's patented analog arc to replicate the response of a moving coil display
- Exceptional measurement range from 20 G½ to 200 G½ - highest insulation test range available on the market, providing a superior range of measurement applications.
- Choice of 20 mA or 200 mA continuity testing - allows user to select lower continuity range thus increasing battery life considerably
- Continuity auto-test capability - enables real twohanded operation without the need to press the test button
- Adjustable continuity limit alarm - allows pass/fail limits to be sent to speed testing
- Automatically perform PI and DAR tests - user is able to quickly perform two important diagnostic tests. . . Polarization Index (PI) and Dielectric Absorption Ratio (DAR)
- True RMS voltage measurement - allows accurate voltage measurement on noisy lines
- Auto ranging voltage measurement - automatically adjusts range from millivolts to 600 V AC or DC,
- eliminating the need to keep changing ranging
- Live circuit warning - automatically warns of contact to a live circuit, voltage is displayed and testing is inhibited
- Auto fuse warning - warns of fuse failure automatically.
- No need to test the fuse manually.
- Buzzer select button - enable or disable buzzer as required with resistance also displayed on the screen
Baker's Dozen Reasons to Buy the MIT400 Series - 13 "sweet" reasons why the MIT's are far superior to those other brands:
- Patented analog/digital display with real-time pointer movement.
- IP54 ingress protection rating
- CAT IV 600 V for all test modes
- Highest resistance range (up to 200 GO) on the market for a hand-held unit
- Dual digital display that shows test voltage (or other complementary information) as well as the measurement result
- Selectable 200 or 20 mA continuity test
- DAR, PI and timed test capability
- TRMS voltage measurement
- Selectable buzzer thresholds/limit alarms
- Unique silicon test leads to improve measurement accuracy
- Automatic fuse check/warning
- 3-year warranty
- Backlight display
In The Box
- Hard carry case
- Red/black test lead set with clips
- 6 AA (LR6) batteries fitted
- Warranty card
- Factory (non-NIST) Calibration Certificate
- Owners CD manual
- Quick start guide
- SP5 remote switched probe
Manuals/Guides
Manuals
- Megger MIT400-2 Series User Manual
- Megger MIT4002 Series 1-KV Insulation Test Equipment - Data Sheet
- Megger Insulation Resistance Testing of Heat Trace Cable Application Note
Manufacturer Specs
| Specifications | |
| Insulation | |
| Insulation Nominal test voltages | 10 V, 25 V, 50 V, 100 V, 250 V, 500 V |
| Insulation resistance range | 10 V - 1 GΩ 25 V - 2 GΩ 50 V - 5 GΩ 100 V - 10 GΩ 250 V - 20 GΩ 500 V - 50 GΩ |
| Range Full Scale Accuracy | 500 V ±3% ±2 digits ±0.4% per GΩ 250 V ±3% ±2 digits ±0.8% per GΩ 100 V ±3% ±2 digits ±2.0% per GΩ 50 V ±3% ±2 digits ±4.0% per GΩ 25 V±3% ±2 digits ±2.0% per 100 MΩ 10 V±3% ±2 digits ±2.0% per 100 MΩ |
| Analogue range | 1 GΩ full scale |
| Resolution | 0.01 MΩ |
| Short circuit current | 2 mA +0% -50% |
| Open circuit terminal voltage | -0% + 20% ±1 V |
| Test current on load | 1 mA at min. pass value of insulation specified in BS7671, HD384and IEC364, 2 mA max. |
| Leakage current range | 0 µA 2000 µA |
| Leakage current | 10% ±3 digits |
| Voltage display | 3% ±3 digits ±0.5% of rated voltage |
| Timer | 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 minute count down in seconds |
| Continuity | |
| Measurement | 0,01 Ω to 99,9 Ω (0 to 100 Ω on analogue scale) |
| Accuracy | ±2% ±2 digits (0 to 100 Ω ) |
| Open circuit voltage | 5 V ±1 V |
| Test current | 200 mA (±1 mA) (0.01 Ω to 9.99 Ω )20 mA (±1 mA ) (10.0 Ω to 99.9 Ω ) |
| Zero offset at probe tips | 0,10 Ω typical |
| Lead resistance zeroing | Up to 9.00 Ω |
| Buzzer | Variable limit 1 Ω , 2 Ω , 5 Ω , 10 Ω , 20 Ω |
| Resistance | |
| Measurement | 0.01 kΩ to 1000 kΩ (0 to 1 MΩ on analogue scale) |
| Accuracy | ±3% ±2 digits |
| Open circuit voltage | 5 V ±1 V |
| Short circuit current | 20 µA ±5 µA |
| Other | |
| Voltage range | 0 to 600 V d.c. ±2% ±2 digits 10 mV to 600 V TRMS sinusoidal (40 to 400 Hz) ±2% ±1 digit 0 to 1000 V on analogue scale Unspecified input level 0 - 10 mV (40 to 400 Hz) |
| Temperature coefficient | <0,1% per °C up to 1 GΩ <0,1% per °C above 1 GΩ |
Tech Specs
Micro / Milli / Meg Ohmmeters/Megohmmeter / Insulation Resistance Testers Template |
|
|---|---|
| IR Test Voltage | 1,000 V, 100 V, 250 V, 50 V, 500 V |
| Maximum Insulation Resistance | 200 G Ohms |
| Automated Test Results | Dielectric Absorption Ratio, Dielectric Discharge, Leakage Current, Other, Step Voltage |
| Type | Battery |
| Minimum Insulation Resistance | 0.01 Ohms (0.00000000001 G Ohms) |
| Variable Incremental Voltage | Yes |
| Display (Megohmmeter) | Analog, Digital, Graphical |
| Continuity Test | Yes |
| Live Circuit Voltage Detection | Yes |
| Power Supply | Battery |
| Timer | Yes |
| CAT Rating | IV |
| CAT Voltage | 600 V |
Test Equipment General Attributes |
|
| Unique Features | True RMS voltage measurement - allows accurate voltage measurement on noisy lines Auto ranging voltage measurement - automatically adjusts range from millivolts to 600 V AC or DC, eliminating the need to keep changing ranges Live circuit warning - automatically warns of contact to a live circuit, voltage is displayed and testing is inhibited Auto fuse warning - warns of fuse failure automatically. No need to test the fuse manually. Buzzer select button - enable or disable buzzer as required with resistance also displayed on the screen |
| Warranty | 3 YEARS |
| Warranty Details | Years 2 and 3 require free registration of the unit. |
| Safety Approval | CE |
| IP Rating | IP54 |
| Product Weight | 27.22 OUNCES (1.70 LBS) |
| Product Height | 2.32 IN |
| Product Length | 9.00 IN |
| Product Width | 4.25 IN |
| Shipping Weight | 32 OUNCES (2 LBS) |
| Data Logging | No |
| HTS/Schedule B Number | 9030.31.0000 |
| ECCN Number | EAR99 |
| Calibration Included | Factory Calibration |
| Battery Type | AA |
| Power Supply Voltage | Battery Powered |
| Country of Origin | United Kingdom |
| Shipping Height | 5 IN |
| Shipping Length | 20 IN |
| Shipping Width | 9 IN |
| Shipping | This Item Ships from Fremantle, Perth, Western Australia |
Please allow 2 - 10 days for your order to arrive.
Although Most Stocked Products will generally Ship Overnight. We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!
Returns are easy.
simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!
