(item no. 4629295)
Product Overview
The Fluke a3000 FC Wireless AC Current Clamp Module is a fully functional true-RMS current clamp meter that wirelessly relays measurements to other Fluke Connect® enabled master units
Features
The a3003 FC Wireless DC Current Clamp Meter is a fully functional current clamp meter that wirelessly relays measurements to other Fluke Connect® enabled master units, listed below:
- Fluke 3000 FC Digital Multimeter
- Fluke Ti200/300/400 Infrared Camera
- PC via optional pc3000 FC Adapter
- Fluke Connect Mobile app
- TiX560 and TiX520
The a3003 FC Wireless 2000 A DC Current Clamp, with its extra-wide jaw, easily clamps around large conductors, typically found in mining, utility, marine, rail or other heavy manufacturing industries where large DC currents or large current carrying cables are found.
The Fluke a3003 FC main features include:
- Measures from 10 A to 2000 A DC
- Large jaw size (64 mm) for measuring large, high current conductors
- Use the logging function for the recording and saving up to 65,000 measurements
- Includes magnetic hanging strap
Specifications: Fluke a3003 FC Wireless 2000 A DC Current Clamp Meter
| DC Current Function | |
| Range | 1.0A to 999.9 A DC 1000 A to 2000 A DC |
| Resolution | 0.1 A 1 A |
| Accuracy | 2% ± 5 digits 2.5% ± 5 digits |
| Specifications | |
| LCD w/backlight | 3 ½ digits |
| Log rate/Interval | 1 sec minimum/adjustable by PC or front pannel |
| Battery type | 2 AA NEDA 15 A IEC LR6 |
| Battery life | 120 hours |
| Memory | Record up to 65,000 readings |
| RF communications | 2.4 GHz ISM Band |
| RF communication range | Open air, unobstructed: Up to 20 m Obstructed, sheetrock wall: Up to 6.5 m Obstructed, concrete wall or steel electrical enclosure: Up to 3.5 m |
| Operating temperature | -10°C to +50°C |
| Storage temperature | -40°C to +60°C |
| Temperature coefficient | Add 0.1 X (specified accuracy) /°C (< 18°C or > 28°C) |
| Operative humidity | 90% at 35°C 75% at 40°C 45% at 50°C |
| Altitude | Operating 2,000 m Storage 12,000 m |
| EMC | EN 61326-1:2013 |
| Safety compliance | IEC 61010-1 600 V CAT IV / 1000 V CAT III 3rd edition |
| Certifications | CSA C-US CE FCC: T68-FBLE IC: 6627A-FBLE |
| Ingress Protection (IP) rating | IP42 |
| Jaw opening | 64 mm |
| Size (HxWxD) | 16.5 mm x 6.35 cm x 1.4 cm (6.5 in x 2.5 in x 1.4 in) |
| Weight | .65 kg (1.75 lb) |
| Note: Not compatible with Fluke CNX test tools. | |
Includes:
- DC current module
- Batteries
- Hanging strap magnet
- Quick start guide
Manuals
| Shipping | This Item Ships from Fremantle, Perth, Western Australia |
Please allow 2 - 10 days for your order to arrive.
Although Most Stocked Products will generally Ship Overnight. We source products from all over the world to bring you epic offers and the lowest prices. This means sometimes you have to wait a little longer to get your order but it's always worth it!
Returns are easy.
simply contact us for a returns number and send your item to our returns centre for fast processing. We'll get you a replacement or refund in a snap!
