GeoDist®100-Touch Laser Distance Meter - Easy operation like a smartphone Touchscreen
The top model with intuitive touchscreen operation - Operate the laser range finder as you are used to on your smartphone
Measurements of distance, area, volume indoors and outdoors up to 100 m.
The top model increases the functions of the GeoDist80 by the longer range of 100 m and the ingeniously simple operation of the extensive functions.
With pointfinder camera: this is the only way to ensure reliable laser distance measurement outdoors at long distances.
The pointfinder camera with 4x zoom function enables exact measurement to the desired target, under all lighting conditions and at long distances. The use with a camera tripod increases the measuring accuracy to a maximum.
The graphical 4-line color display is easy to read under all conditions and can be rotated for measurements in other positions.
Functional integrated tilt sensor 360°:
- Helps the user to keep the instrument exactly horizontal for highest accuracy
- Angle measurement and leveling
- Ingenious- indirect height and distance measurements in high accuracy .Where direct measurements are not possible e.g. due to glass facade without measurement reflection or if the measurement object is partly covered by e.g. mounds, building materials, furniture: One distance measurement to any position at the object is sufficient - the device automatically calculates horizontal distance and height.
- Convenient, high measurement reliability and accuracy - much better than with pythagoras functions
Comprehensive functions of a device of the professional class: distance measurement up to 80 m, various area/volume measurements, min/max, plus/minus, offset, time-delayed measurement, stakeout.
Professional quality: Dust/water protection IP65, 2 m drop protection, shock and temperature resistant PC-ABS plastic.
Environmentally friendly: rechargeable NiMH batteries save battery purchase.
Data processing as you would expect in this class: 1000 measured values internal memory, data transfer via USB or Bluetooth®.
Free GeoDist®CONNECT APP for Android and iOS for digital processing of the measurements:
Photograph and dimension measurement situations, dimension imported photos, create and dimension sketches, create measurement data lists in Excel.
Export in the formats dwg/pdf/bmp/xls e.g. by e-mail for further processing.
Features
- Distance/Volume/Area
- Continuous/max/min
- Plus-/minus
- Offset +/- & Stake out
- Colour display / rotatable
- Point-finder Camera / 4 x Zoom
- 1/4" tripod connection
- 4 x 90° tilt measurement
- Point of reference: front, tripod, rear
- Point to point (3D) measurement
- Pythagoras measurements
- Automatic height & distance (via tilt measurement)
- Trapezoid measurements
- Triangle/circular area
- Cylindrical volume
- Data storage (last 1000 values)
- Data export via Bluetooth & USB
- GeoDist®Connect App (Android & iOS)
Specifications
| Measuring range* | 0.2 - 100 m |
| Measuring accuracy** | ± 2 mm |
| Tilt measurement accuracy | +/-0.3° |
| Measuring units | m /ft / in / ft+in |
| Battery type | NiMH rechargeable |
| (alternatively alkaline AAA) | |
| IP protection class | IP 65 |
| Temperature range | -10 to 40°C |
| Laserdiode | red / class 2 |
| Weight (incl. Batteries) | 152 g |
| *May be shorter under unfavourable conditions | |
| **Typical accuracy, may increase under unfavourable conditions | |
geo-FENNEL: GeoDist®️100-TOUCH Video
Included
- NiMH batteries
- USB Charging cable
- Holster
- Hand strip
Download
